Gintex-Modcomfort 200 Arc Flash Protection along with Heat & Flame Resistance

Availability:
Quantity:
Inquire Add to Basket

  • Modcomfort 200

  • GINTEX

Specification
Gintex-Modcomfort200: Arc Flash Protection along with Heat & Flame Resistance

Fabric name: Gintex-Modcomfort200
Composition: Modacrylic / Lyocell / Para-aramid / Anti-static
Weight: 200 ± 5% gsm
Width: 150 ± 2 cm
Structure: Twill
Finish: Softhand feeling
Color: Navy blue, Royal blue, Fluorescent or OEM
Standards: EN ISO 11611, EN ISO 11612, EN 61482-2, NFPA 2112, ASTM F1959, ASTM F1930, EN 1149-5
Features: CAT2 (ATPV 8 cal/cm²), Inherently FR, Lightweight
Application: Power Grid, Power Substations, Electrical Maintenance, Mining Electrical Operations
Typical Garment: Jackets, Trousers, Coveralls
Overview
At 200 gsm, this lightweight inherent FR twill is made from modacrylic, lyocell, para-aramid and anti-static fibers, with a softhand finish. It is tested to ASTM F1959 (ATPV 8 cal/cm²), EN 61482-2 (APC 1), NFPA 2112 and ASTM F1930, and also meets EN ISO 11611, EN ISO 11612 and EN 1149-5.
Why It Works

Arc protection: ATPV 8 cal/cm² (ASTM F1959) and APC 1 (EN 61482-2) in a lightweight 200 gsm twill.

Flash fire: NFPA 2112 PASS, with an ASTM F1930 manikin test result of 24.04% (UL Listed).

Inherent FR fibers: modacrylic and para-aramid with lyocell and anti-static fibers.

Softhand finish: a soft-feeling finish for wearing comfort.

Strength: tensile 900 N warp / 700 N weft, tear 36 N warp / 35 N weft.

Abrasion resistance: over 10,000 cycles at 12 kPa.

Dimensional stability: -1.8% warp / -0.4% weft after 5 × 60°C washes.

Pilling resistance: grade 4 after 2000 cycles.
