Gintex-ModT195 Inherent FR Fabric for Reliable Arc Protection

Availability:

Quantity:



Inquire Add to Basket

Model:
ModT195
Brand:
GINTEX

Specification

Gintex-ModT195: Inherently FR, Lightweight Arc Protection

Fabric name: Gintex-ModT195

Composition: Modacrylic / Cotton / Para-aramid / Nylon / Anti-static

Weight: 195 ± 5% gsm

Width: 150 ± 2 cm

Structure: Ripstop Twill

Finish: UV treatment

Color: Navy blue, Royal blue, Fluorescent or OEM

Standards: EN ISO 11611, EN ISO 11612, NFPA 2112, ASTM F1959, EN 61482-1-2, EN 1149-3

Features: Inherently FR, Lightweight, Comfortable

Application: Power Grid, Power Substations, Electrical Maintenance, Mining Electrical Operations

Typical Garment: Jackets, Coveralls

Overview

At 195 gsm, this lightweight ripstop twill is made from modacrylic, cotton, para-aramid, nylon and anti-static fibers, with a UV treatment finish. It is tested to ASTM F1959 (ATPV 8.8 cal/cm²), 61482-1-2 (APC 1) and NFPA 2112, and also meets EN ISO 11611, EN ISO 11612 and EN 1149-3.

Why It Works



Arc protection: ATPV 8.8 cal/cm² (ASTM F1959) and APC 1 in a lightweight 195 gsm fabric.

Flash fire: NFPA 2112 PASS.

Inherent FR fibers: modacrylic and para-aramid, blended with cotton, nylon and anti-static fibers.

Ripstop twill structure: tear strength 34 N warp / 32 N weft, similar in both directions.

Abrasion resistance: over 10,000 cycles at 12 kPa.

Dimensional stability: -0.4% warp / -0.2% weft after 5 × 60°C washes.

UV treatment finish.

Anti-static: EN 1149-3 PASS.

Technical Data Sheet

Certificates

ripstop FR fabric arc flash fabric inherent FR fabric utility workwear fabric arc flash coverall fabric
