Gintex-FRCN300A FR Cotton/Nylon Satin with ATPV 13 cal/cm² and NFPA 2112

Availability:
Quantity:
Inquire Add to Basket

  • FRCN300A

  • GINTEX

Specification
Gintex-FRCN300A: Superior Arc Protection with Exceptional Value


Fabric name: Gintex-FRCN300A
Composition: Cotton / Nylon with Anti-static
Weight: 300 ± 5% gsm
Width: 150 ± 2 cm
Structure: Satin
Finish: FR Treatment
Color: Navy blue, Royal blue, Fluorescent or OEM
Standards: EN ISO 11611, EN ISO 11612, NFPA 2112, ASTM F1959, ASTM F1930, ISO 61482-1-2, EN 1149-3
Features: FR Treated, Durable, Economic
Application: Power Plants, Electric Utility, Power Grid, Power Substations
Typical Garment: Jackets, Trousers, Coveralls
Overview
At 300 gsm, this FR-treated satin fabric is made from cotton, nylon and anti-static fibers. It is tested to ASTM F1959 (ATPV 13 cal/cm²), ISO 61482-1-2 (APC 1), NFPA 2112 and ASTM F1930 (UL Listed), and also meets EN ISO 11611, EN ISO 11612 and EN 1149-3.
Why It Works

Arc protection: ATPV 13 cal/cm² (ASTM F1959) and APC 1 (ISO 61482-1-2).

Flash fire: NFPA 2112 PASS, with an ASTM F1930 manikin test result of 10.11% (UL Listed).

FR treatment finish on a cotton/nylon satin structure, with anti-static fibers (EN 1149-3 PASS).

Strength: tensile 1047 N warp / 523 N weft, tear 39 N warp / 27 N weft.

Abrasion resistance: over 10,000 cycles at 12 kPa.

Dimensional stability: -2.2% warp / -2.1% weft after 5 × 60°C washes.

Pilling resistance: grade 4 after 2000 cycles.
