Gintex-A200: Enhanced Flame Resistant & Durable Protection
Fabric name: Gintex-A200
Composition: 93% Meta-aramid / 5% Para-aramid / 2% Anti-static
Weight: 200 ± 5% gsm
Width: 150 ± 2 cm
Structure: Twill
Finish: Moisture Absorption and Sweat Releasing
Color: Navy blue, Royal blue, Fluorescent or OEM
Standards: EN ISO 11611, EN ISO 11612, NFPA 2112, EN IEC 61482-2, EN 1149-5, ASTM F1930
Features: Inherent FR, High Strength, Durability, Moisture Absorption and Sweat Releasing
Application: Oil & Gas, Petrochemical, Heavy Industry
Typical Garment: Jackets, Trousers
Overview
At 200 gsm, this twill fabric is made from 93% meta-aramid, 5% para-aramid and 2% anti-static fibers, with a moisture absorption and sweat releasing finish. It is tested to NFPA 2112, EN IEC 61482-2 (APC 1) and ASTM F1930 (UL Listed), and also meets EN ISO 11611, EN ISO 11612 and EN 1149-5.
Why It Works
Flash fire: NFPA 2112 PASS, with an ASTM F1930 manikin test result of 20.22% (UL Listed).
Inherent FR fibers: 93% meta-aramid and 5% para-aramid, with 2% anti-static fibers (EN 1149-5 PASS).
Strength: tensile 1400 N warp / 1100 N weft, tear 52 N warp / 53 N weft.
Abrasion resistance: over 50,000 cycles at 12 kPa.
Moisture absorption and sweat releasing finish.
Dimensional stability: -1.1% warp / -0.1% weft after 5 × 60°C washes.
Pilling resistance: grade 4 after 5000 cycles.
