Gintex-A150: Inherent Flame Resistant Multi-Protection Solution
Fabric name: Gintex-A150
Composition: 93% Meta-aramid / 5% Para-aramid / 2% Anti-static
Weight: 150 ± 5% gsm
Width: 150 ± 2 cm
Structure: Plain
Finish: Moisture Absorption and Sweat Releasing
Color: Navy blue, Royal blue, Fluorescent or OEM
Standards: EN ISO 11611, EN ISO 11612, NFPA 2112, ASTM F1930, EN 1149-5
Features: Inherent FR, High Strength, Light-weight, Moisture Absorption and Sweat Releasing
Application: Oil & Gas, Petrochemical
Typical Garment: Shirts, Coveralls
Overview
At 150 gsm, this plain-structure fabric is made from 93% meta-aramid, 5% para-aramid and 2% anti-static fibers, with a moisture absorption and sweat releasing finish. It is tested to NFPA 2112 and ASTM F1930 (UL Listed), and also meets EN ISO 11611, EN ISO 11612 and EN 1149-5.
Why It Works
Flash fire: NFPA 2112 PASS, with an ASTM F1930 manikin test result of 29.78% (UL Listed).
Inherent FR fibers: 93% meta-aramid and 5% para-aramid, with 2% anti-static fibers (EN 1149-5 PASS).
Lightweight: 150 gsm plain structure.
Strength: tensile 1160 N warp / 756 N weft, tear 44 N warp / 42 N weft.
Abrasion resistance: over 50,000 cycles at 12 kPa.
Moisture absorption and sweat releasing finish.
Dimensional stability: -0.9% warp / -0.5% weft after 5 × 60°C washes.
Pilling resistance: grade 4 after 5000 cycles.
